Fire Wraps
The Allproof Passive Fire Wraps are designed and tested on a wide range of plastic plumbing pipes through concrete walls/floors and plasterboard walls with a fire band. The passive fire wraps consist of one or more layers of intumescent material sealed in a polyethylene sleeve.
In the event of a fire, the intumescent material is activated and expands into the penetration cavity as the penetration service melts and deforms. When the intumescent seal expands, it forms a fire-resistant seal in the penetration, preventing the spread of fire.
The pipe wrap is designed to have the ends of the intumescent material meet around the circumference of the pipe. No overlap will exist, allowing the pipe to be centrally located within a core hole. For pipe sizes up to 100mm, only one layer of intumescent material is required, ensuring core holes can be kept to a minimum size. For plasterboard walls, a galvanized fire band is required to hold the fire wraps in place.
The Allproof Passive Fire Wraps have been tested at accredited fire laboratories in accordance with AS 1530.4 and AS 4072.1. The passive fire wraps have been tested and designed to be installed on the underside of flooring substrates for stack systems only. For plasterboard walls, the wraps need to be installed inside the walls using the fire band.
Original: $8.06
-65%$8.06
$2.82More Images
Fire Wraps
The Allproof Passive Fire Wraps are designed and tested on a wide range of plastic plumbing pipes through concrete walls/floors and plasterboard walls with a fire band. The passive fire wraps consist of one or more layers of intumescent material sealed in a polyethylene sleeve.
In the event of a fire, the intumescent material is activated and expands into the penetration cavity as the penetration service melts and deforms. When the intumescent seal expands, it forms a fire-resistant seal in the penetration, preventing the spread of fire.
The pipe wrap is designed to have the ends of the intumescent material meet around the circumference of the pipe. No overlap will exist, allowing the pipe to be centrally located within a core hole. For pipe sizes up to 100mm, only one layer of intumescent material is required, ensuring core holes can be kept to a minimum size. For plasterboard walls, a galvanized fire band is required to hold the fire wraps in place.
The Allproof Passive Fire Wraps have been tested at accredited fire laboratories in accordance with AS 1530.4 and AS 4072.1. The passive fire wraps have been tested and designed to be installed on the underside of flooring substrates for stack systems only. For plasterboard walls, the wraps need to be installed inside the walls using the fire band.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The Allproof Passive Fire Wraps are designed and tested on a wide range of plastic plumbing pipes through concrete walls/floors and plasterboard walls with a fire band. The passive fire wraps consist of one or more layers of intumescent material sealed in a polyethylene sleeve.
In the event of a fire, the intumescent material is activated and expands into the penetration cavity as the penetration service melts and deforms. When the intumescent seal expands, it forms a fire-resistant seal in the penetration, preventing the spread of fire.
The pipe wrap is designed to have the ends of the intumescent material meet around the circumference of the pipe. No overlap will exist, allowing the pipe to be centrally located within a core hole. For pipe sizes up to 100mm, only one layer of intumescent material is required, ensuring core holes can be kept to a minimum size. For plasterboard walls, a galvanized fire band is required to hold the fire wraps in place.
The Allproof Passive Fire Wraps have been tested at accredited fire laboratories in accordance with AS 1530.4 and AS 4072.1. The passive fire wraps have been tested and designed to be installed on the underside of flooring substrates for stack systems only. For plasterboard walls, the wraps need to be installed inside the walls using the fire band.
