Name: Moda Spring Hinge - Satin Chrome Plate
Brand: Plumbing Supplies
SKU: moda-spring-hinge-satin-chrome-plate
Availability: InStock

✨ New Arrivals Just Dropped!Explore

Moda Spring Hinge - Satin Chrome Plate

Material	Diecast Zinc, Alloy ZP3 Brass Shaft Nylon Inserts ABS Snap-On Covers
Finish	Satin Chrome Plate
Mounting	Concealed Screw Fix or Bolt Through
Minimum Hinge Clearance For Lift-Off Hinges	35mm
Specify	MODA_LHSPRING_SCP: Left Hand MODA_RHSPRING_SCP: Right Hand
Features	Spring-assisted door opening/door closing Fully Adjustable Spring to suit door - No Tension to Full Tension Spring Reversible Hold Open / Hold Closed Liftoff capability
Load Rating	15Kg per hinge
	For optimum performance - 2 hinges per door up to 30Kgs For doors over 30Kg allow for 15Kg per hinge Note: 3 Hinges per door is recommended to prevent door bowing
Note	For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate only) All hinges are available with or without fixings. Please nominate your requirements at the time of ordering.

$9.05

Original: $25.85

-65%

Moda Spring Hinge - Satin Chrome Plate—

$25.85

$9.05

Original: $25.85

-65%

Moda Spring Hinge - Satin Chrome Plate—

$25.85

$9.05

More Images

Moda Spring Hinge - Satin Chrome Plate

Material	Diecast Zinc, Alloy ZP3 Brass Shaft Nylon Inserts ABS Snap-On Covers
Finish	Satin Chrome Plate
Mounting	Concealed Screw Fix or Bolt Through
Minimum Hinge Clearance For Lift-Off Hinges	35mm
Specify	MODA_LHSPRING_SCP: Left Hand MODA_RHSPRING_SCP: Right Hand
Features	Spring-assisted door opening/door closing Fully Adjustable Spring to suit door - No Tension to Full Tension Spring Reversible Hold Open / Hold Closed Liftoff capability
Load Rating	15Kg per hinge
	For optimum performance - 2 hinges per door up to 30Kgs For doors over 30Kg allow for 15Kg per hinge Note: 3 Hinges per door is recommended to prevent door bowing
Note	For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate only) All hinges are available with or without fixings. Please nominate your requirements at the time of ordering.

Material	Diecast Zinc, Alloy ZP3 Brass Shaft Nylon Inserts ABS Snap-On Covers
Finish	Satin Chrome Plate
Mounting	Concealed Screw Fix or Bolt Through
Minimum Hinge Clearance For Lift-Off Hinges	35mm
Specify	MODA_LHSPRING_SCP: Left Hand MODA_RHSPRING_SCP: Right Hand
Features	Spring-assisted door opening/door closing Fully Adjustable Spring to suit door - No Tension to Full Tension Spring Reversible Hold Open / Hold Closed Liftoff capability
Load Rating	15Kg per hinge
	For optimum performance - 2 hinges per door up to 30Kgs For doors over 30Kg allow for 15Kg per hinge Note: 3 Hinges per door is recommended to prevent door bowing
Note	For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate only) All hinges are available with or without fixings. Please nominate your requirements at the time of ordering.
