Touch-Activated Single Flush WC Flushing System – Duct Access

Touch-Activated Single Flush WC Flushing System – Duct Access

Enware’s WC flushing systems provide a neat and reliable flushing solution using piezoelectric technology particularly suited for public access applications. Uses a WaterMarked solenoid that when combined with an appropriate pan delivers a 5.5 litre flush.
Best suited for duct style installation (Flush unit and activation plate MUST be seperated).
Semi concealed installation with a stainless steel panel and security screws. Shut off valve, filter and airbreak included. Suitable for AS1428.1 applications.

  • Piezo touch button control
  • Mains power 24V
  • Compact face plate
  • Vandal resistant torx screws
  • WMTS-020 compliant
  • 3-year warranty
  • WaterMark: WMTS-020 C of C 40116 Global-Mark
  • WELS: 1 Star Rating

INLET & OUTLET

Connection Inlet - 1" BSP (25mm)

PRESSURE

Dual Flush Water Supply Working Pressure 300kPa
Single Flush Water Supply Working Pressure 250kPI

FLUSH

Flush Pipe 700mm (+/- 100mm) of 1 1/2" (40mm) flush pipe is required below the air break.

FLOW RATE

Kv Factor 8.3m3/h

POWER SOURCE

Mains Powered 24V AC Transformer

SUPPLY LINE

Minimum Water Supply Line Size 1" (25mm) copper pipe
$840.97
Touch-Activated Single Flush WC Flushing System – Duct Access—
$840.97

More Images

Touch-Activated Single Flush WC Flushing System – Duct Access - Image 2

Touch-Activated Single Flush WC Flushing System – Duct Access

Enware’s WC flushing systems provide a neat and reliable flushing solution using piezoelectric technology particularly suited for public access applications. Uses a WaterMarked solenoid that when combined with an appropriate pan delivers a 5.5 litre flush.
Best suited for duct style installation (Flush unit and activation plate MUST be seperated).
Semi concealed installation with a stainless steel panel and security screws. Shut off valve, filter and airbreak included. Suitable for AS1428.1 applications.

  • Piezo touch button control
  • Mains power 24V
  • Compact face plate
  • Vandal resistant torx screws
  • WMTS-020 compliant
  • 3-year warranty
  • WaterMark: WMTS-020 C of C 40116 Global-Mark
  • WELS: 1 Star Rating

INLET & OUTLET

Connection Inlet - 1" BSP (25mm)

PRESSURE

Dual Flush Water Supply Working Pressure 300kPa
Single Flush Water Supply Working Pressure 250kPI

FLUSH

Flush Pipe 700mm (+/- 100mm) of 1 1/2" (40mm) flush pipe is required below the air break.

FLOW RATE

Kv Factor 8.3m3/h

POWER SOURCE

Mains Powered 24V AC Transformer

SUPPLY LINE

Minimum Water Supply Line Size 1" (25mm) copper pipe
